Screw Air Compressor
产品类别: 查看更多产品列表

Combined Screw Air Compressor

关注度: 6202
这是描述信息
  产品概要:
With the best Diesel Engline has reasonably adjust the air delivery and power,wich can meet the requirements of heavy duty use and most harsh field application environment, and treatly reduce fuel consumption and the operation cost. Beautiful appearance, reliable performance and excellent economy.
马上询价 Combined Screw Air Compressor QQ咨询
想了解更多玉达空压机产品详情,请直接联系我们,我们将给您最详细的设备方案和最优惠的价格!
数量
-
+
库存:
0
1
产品描述
参数

Product Features:

With the best Diesel Engline has reasonably adjust the air delivery and power,wich can meet the requirements of heavy duty use and most   harsh field application environment, and treatly reduce fuel consumption and the operation cost. Beautiful appearance, reliable performance and excellent economy.


1. The combined screw air compressor that integrates the entire air system solution is not only an integrated compressed air system, but also a complete compressed air solution.

2. Long and reliable operating time, high productivity, flexible operation, low operating noise, high energy efficiency and cost savings.

3. The integrated design eliminates the use of internal pipes and joints.

4. Automatic start / stop control and constant speed running controller.

5. Easy-to-maintain direct drive, no need to replace wearing parts such as belts.


Model

YD-10AT

YD-15AT

YD-20AT

Air   pressure (Mpa)

0.8

0.8

0.8

Air   delivery (FAD)   (m³/min)

1.05

1.52

2.3

Input   power (Kw)

8.78

7.98

8.71

Type   of cooling

风冷  Air-cooling

Outlet temperature ()

环境温度 Ambient temperature ±12

Power (Kw)

7.5

11

15

Speed (r/min)

1470

2900

2920

Voltage (V/PH/Hz)

380/3/50

380/3/50

380/3/50

Starting   method

直接驱动 Direct Driven

Y-△启动

Y-△启动

Insulation   level

F

F

F

Protection   level

IP54

IP23/IP54

IP23/IP54

Applicable   temperatrue range ()

-5+42

-5+45

-5+45

Driven   method

直联驱动 Direct Driven

Noise   level

62±2

64±2

66±2

Oil   content

3

3

3

Coolant   capacity (L/)

4.5

9

9

Tank (L)

130

145

150

Outlet   connection size

G½″

G¾

G¾

Weight (Kg)

≈275

≈450

≈480

Dimension (mm)

1000×700×1270

1050×750×1400

1050×750×1380
